The Axial Compression Capacity of Finger-Jointed Laminated Board Made from Rubber Wood Species
DOI:
https://doi.org/10.9744/ced.27.2.113-122Keywords:
finger-jointed laminated board, rubberwood species, axial compression capacity, affordable housing, buckling failureAbstract
The utilisation of Rubberwood was an effort to provide an alternative to low-cost housing in Indonesia. This study investigated the use of Rubberwood Finger-Jointed Laminated Board (FJLB) under compression loading parallel to the grain. The investigation included laboratory experiments and numerical analysis. The experiments were conducted using two specimens of FJLB members, each with a length of 2000 mm and a cross-sectional dimension of 100 mm × 100 mm². Finite element analysis (FEA) was employed to predict the axial capacity, considering non-linearity, contact boundary conditions, and buckling analysis of the material. The study found an average axial capacity of 150.9 kN for the two specimens, which was 3.2% higher than the FEA and 5.4% higher compared to the Euler formula. Laboratory measurements revealed that initially, the stress distribution in the cross-section was uniform, then suddenly changed to a combination of tension and compression during the final loading stage.
References
Statistics Indonesia, Percentage of Households with Access to Adequate and Affordable Housing, 2022. https://www.bps.go.id/indicator/29/1241/1/perse
Statistics Indonesia, Indonesia Population Projection, 2017.
Jakarta Property Institute, Middle Class Housing Demand Fulfillment Potential Through Co-Residence, 2023.
Purnamasari, L. Effect of Government’s Policy to Build 1 Million Houses on Performance of Housing and Apartment Credits of Banks Listed in Indonesia Stock Exchange during Period 2015-2017, Jurnal Ilmiah Ilmu Administrasi Publik, 11(1), 2021, pp. 40-50. https://doi.org/10.26858/jiap.v11i1.19777
Cabinet Secretariat Indonesia, The Realisation of the Million Houses Program in 2021 Successfully Reaches 1.11 Million Units, 2022. https://setkab.go.id/realisasi-program-sejuta-rumah-tahun-2021-capai-111-juta-unit/
Hidayah, N., Satyarno, I., and Saputra, A Housing Rehabilitation and Reconstruction in Central Sulawesi Post-2018 Earthquake, E3S Web Conference, 200, 2020. https://doi.org/10.1051/e3sconf/202020003004
Sutrisno, W., Satyarno, I., Awaludin, A., Saputra, A., and Setiawan, A.F., Seismic Performance of Instant Steel Frame House for Post Earthquake Reconstruction, Lecture Notes in Civil Engineering, 215, 2022. https://doi.org/10.1007/978-981-16-7924-7_6
Octavia, S., Awaludin, A., and Wusqo, U., Lateral Resistance FJLB Rubberwood Double Shear Connection–Steel Plate with Bolt Connection, Jurnal Riset Rekayasa Sipil, 6, 2022, pp. 21–32. https://doi.org/10.20961/jrrs.v6i1.62337
Suta, K., Irawanto, E., Rahmawati, H.V., and Widayanti, B.H., The Effectiveness of the Construction of Risha, Rika and Riko (3R) Houses for Earthquake Affected Communities, Journal Planoearth, 5, 2020, pp. 20-24. https://doi.org/10.31764/jpe.v5i1.2178
Junior, H.J E., Ohto, J.M., Silva, L.L., Palma, H.A.L., and Ballarin, A.W., Potential of Rubberwood (Hevea Brasiliensis) for Structural Use after The Period of Latex Extraction: A Case Study in Brazil. Journal of Wood Science, 61, 2015, 384–390. https://doi.org/10.1007/s10086-015-1478-7
Junior, H.J.E., Ohto, J. M., Silva, L.L., Palma, H.A.L., and Ballarin, A.W., Potential of Rubberwood (Hevea Brasiliensis) for Structural Use after The Period of Latex Extraction: A Case Study in Brazil, Journal of Wood Science, 61, 2015, pp. 384–390. https://doi.org/10.1007/s10086-015-1478-7
Shulhan, M.A., Awaludin, A., Nugroho, M.S., and Octavia, S., Flexural Behaviour Study of Finger Jointed Laminated Board (FJLB) Made from Kayu Karet (Hevea Brasiliensis). Media Komunikasi Teknik Sipil, 28(2), 2022, pp. 169-177. https://doi.org/10.14710/mkts.v28i2.45714
Gustavsson, L., Joelsson, A., and Sathre, R., Life Cycle Primary Energy Use and Carbon Emission of An Eight-Story Wood-Framed Apartment Building, Journals of Energy and Buidings, 42, 2010, pp. 230–242. https://doi.org/10.1016/j.enbuild.2009.08.018
Guardigli, L., Monari, F., and Bragadin, M.A., Assessing Environmental Impact of Green Buildings through LCA Methods: A Comparison between Reinforced Concrete and Wood Structures in the European Context, Procedia Engineering, 21, 2011, pp. 1199–1206. https://doi.org/10.1016/j.proeng.2011.11.2131
Nugroho, N. and Bahtiar, T.E., Buckling Formulas for Designing A Column with Gigantochloa Apus, Case Study of Construction and Material, 14, 2021, 00516. https://doi.org/10.1016/j.cscm.2021.e00516
Li, H.T., Su, J.W., Zhang, Q.S., Deeks, A.J., and Hui, D., Mechanical Performance of Laminated Bamboo Column under Axial Compression, Composite Part B: Engineering, 79, 2015, pp. 374–382. https://doi.org/10.1016/j.compositesb.2015.04.027
Zhou, S.C., Chu, F.Z., Lu, X.H., and Xiao, Y., Experimental Studies on Glubam Columns under Axial Compression, Journal of Building Engineering, 49, 2022. https://doi.org/10.1016/j.jobe.2021.103453
Awaludin, A., Rachmawati, K., Aryati, M., and Danastri, A.D., Development of Cold Formed Steel - Timber Composite for Roof Structures: Compression Members, Procedia Engineering, 125, 2015, pp. 850–856. https://doi.org/10.1016/j.proeng.2015.11.052
Bahtiar, E.T., Malkowska. D., Trujillo, D., and Nugroho, N., Experimental Study on Buckling Resistance of Guadua Angustifolia Bamboo Column, Engineering Structure, 228, 2021, p. 111548. https://doi.org/10.1016/j.engstruct.2020.111548
Anshari, B., Guan, Z.W., and Wang, Q.Y., Modelling of Glulam Beams Pre-stressed by Compressed Wood, Composite Structure, 165, 2017, pp. 160–170. https://doi.org/10.1016/j.compstruct.2017.01.028
Sandhaas, C. and Kuilen, J.W.G., Material Model for Wood, Heron, 53, 2013, pp. 179–200
Fueyo, J.G., Cabezas, J.A., Domínguez, M, Anton, N., and Villarino., A., Energy Distribution in Dowel-Type Joints in Timber Structures When Using Expansive Kits. Forests, 12(9), 2021, pp. 1–21. https://doi.org/10.3390/f12091200
Buchanan, A.H., Bending Strength of Lumber, Journal of Structural Engineering, 116, 1999, pp. 1213–1229. https://doi.org/10.1061/(ASCE)0733-9445(1990)116:5(1213)
Awaludin, A., Irawati, I.S., and Shulhan, M.A., Two-dimensional Finite Element Analysis of The Flexural Resistance of LVL Sengon Non-Prismatic Beams, Case Study of Construction and Material, 10, 2019. https://doi.org/10.1016/j.cscm.2019.e00225
Effendi, M.K. and Awaludin, A., Nonlinear Finite Element Analysis of Flexural Laminated Veneer Lumber (LVL) Sengon Slender Beam, Civil Engineering Dimension, 24(2), 2022, pp. 85-92. https://doi.org/10.9744/CED.24.2.85-92
Shakimon, M.N., Malek, N.J.A., Hassan, R., and Ahmad, Z., The Finite Element Modelling of Glulam Tropical Timber Beam in Bending, Jurnal Teknologi, 78, 2016. https://doi.org/10.11113/jt.v78.8579
Serrano, E. and Larsen, H.J., Numerical Investigations of the Laminating Effect in Laminated Beams, Journal of Structural Engineering, 125, 1999, pp. 740–745. https://doi.org/10.1061/(ASCE)0733-9445(1999)125:7(740)
Nali P.C. and Carrerra, E., A Numerical Assessment on Two-Dimensional Failure Criteria for Composite Layered Structures, Composite Engineering, 43, 2012, pp. 280–289. https://doi.org/10.1016/j.compositesb.2011.06.018
Zienkiewicz, O.C. and Taylor, R.L., The Finite Element Method for Solid and Structural Mechanics, Elsevier Butterworth-Heinemann, 2005.
ADINA R&D Inc., Theory and Modelling Guide Volume I, Report ARD 12-8, Watertown, 2012.
Zhang, J., He, M., and Li, Z., Compressive Behavior of Glulam Columns with Initial Cracks under Eccentric Loads, Journal of Advance Structural Engineering, 10, 2018, pp. 111–119. https://doi.org/10.1007/s40091-018-0181-5
Pina, J.C., Flores, E.I.S., and Saavedra, K., Numerical Study on The Elastic Buckling of Cross-Laminated Timber Walls Subject to Compression, Construction and Building Materials, 199, 2018, pp. 82–91. https://doi.org/10.1016/j.conbuildmat.2018.12.013
Singer, J., Arbocz, J., and Weller, Buckling Experiments: Experimental Methods in Buckling of Thin-walled Structures, John Wiley and Sons, 2002.
